How to Measure for a Custom Kennel Cover (2026)

How to Choose the Right Product

How to Choose the Right Kennel Cover

Start with the fitting problem you want to solve: unwanted sun, rain, drafts, or sagging panels. Accurate measurement is the foundation of a custom cover that fits — measure the OUTSIDE dimensions of the kennel (length, width, height) where the cover will sit. Record the location and spacing of any attachment points (posts, rails, or hooks) and note whether you want the cover to wrap around edges or stop flush with the frame. Use a metal tape measure for straight runs and a laser measure for larger outdoor runs; write down three measurements (front, middle, back) for both width and length if the run isn't perfectly square and use the smallest measurement as your base.

Allow for overlap: add 2–4 inches per side for zip-ties or bungee fasteners; for heavy waterproof tarps you may want 4–6 inches to avoid tension at the grommets. Choose material based on climate and airflow needs: HDPE mesh (breathable) reduces heat buildup and is lighter to handle, while 220 GSM polyethylene tarps give dual sun-and-rain protection but require precise measurement because thicker material won’t stretch. Pay attention to grommet placement — products with evenly spaced grommets let you match measured spacing and prevent droop. Finally, use the vendor’s custom-size form carefully: enter the outside dimensions and specify how you want the cover finished (hemmed edges, reinforced corners, grommet intervals). If you're between sizes, choose the slightly larger custom dimension and plan to anchor with elastic or bungee for tensioning without overstressing seams.

Tools, templates and tips

Tools: metal tape, laser distance measurer, marker, paper template. Make a paper or cardboard template (cut to your measured dimensions) and test fit it over the kennel to check for interference points like hinges or bolts. Note anchor points and measure center-to-center distances between them — this lets you pick grommet intervals that line up. Templates are especially helpful for angled roofs or peaked frames.

Budget Tiers

Budget (HDPE, breathable): Best for owners who need shade, airflow, and a forgiving fabric for easy installation. Mid-range: Balanced options that offer better build quality and grommet systems for a secure fit. Premium (220 GSM waterproof): Choose for full weather protection and durability — requires more accurate measuring and may cost more but reduces the need for multiple covers over time.
